1 Introduction

At present, CAD tools encourage use at each stage a 3D approach (from the product design stage to final inspection). The 3D approach is relatively well controlled and well integrated, especially in design office [1] and metrology [2]. By cons, during manufacture, process control is complex [3]. In practice, it is mainly through the steering translation adjustment parameters (gauges tools, original program, instructions axes). The driving of setting parameters of rotation (parallelism, perpendicularity …) is fixed by the geometry of the process (machine tools, assembly) [4]. In particular, experimental work of Bui [5] showed that:

  • Quantification of angular defects requires means of complex measurement and analysis [2,6].

  • The dispersion of results obtained on the components of rotation is same order than the intrinsic defects obtained in production [7].

In this article, we will try to show that a 3D approach is not necessary in all cases, and that, a 1D approach is often sufficient and avoids a measure of heaviness and treatment. This proposal will be supported by a real experiment on machine tools.

2 Definition of a distance in space travel

2.1 Displacement

The objective is to compare two characteristics of the part − a target characteristic and a realization (a machining part will be called individual).

The characteristic corresponds to the relative position of two elements of references (reference systems related to surfaces or groups of surfaces). This is a displacement of solids (reference systems of associated references):

  • a translation. TO,AB (for target) and Tk,AB (for the kth individual);

  • a rotation RO,AB (for target) and Rk,AB (for the kth individual).

In the book [8], it is said: it will always express the relative position of two surfaces by displacement said “significant” that superimposes geometric parameters of position of the two surfaces.

If the association of reference systems to surfaces is controlled, we can then compare the two displacements (individual and target). They are defined by the passage of the R1 reference system to R2 [9]. These two coordinate systems are related by the displacement D ={ TO1→O2 ; RO1→O2 }, which is shown in Figure 1.

The position of a geometric vector can be expressed in two reference systems (Eq. (1)): (1)

If we called R matrix (Eq. (2)): (2)

We obtain the following equation: (3)

Particular case where A is equal to O1 (Eq. (4)): (4)

This transformation preserves the lengths and angles. It is an isometry.

thumbnail Fig. 1

Systems of coordinate.

2.2 Identification of moving target (definition)

In the case of two parallel planes, the choice of the coordinate system is quite arbitrary. There are three degrees of freedom for this choice: two translations in the plan and one orientation. The “Good mechanical meaning” restricts this choice. There are still many opportunities.

2.2.1 Didactics example

In this example (Fig. 2), we will confine ourselves to the position of the upper surface to the basic plane A.

The choice of R1 is pretty easy on this part because we have three references (surfaces A, B and C). The choice is unique if we take the framed sides of “40” to fix the origin. Edge effect of B and C surfaces is very important [10]. The unique definition of a coordinate system is often implicit. This may generate an error of interpretation in the declaration of conformity.

For the particular case of target example (Fig. 3), we have the following equation: (5)

Either numerically: (6)

thumbnail Fig. 2

Drawing of definition of the used part.

thumbnail Fig. 3

Presentation of target part.

2.3 Identification of displacement on an individual

To compare the two movements (target and individual), they must be defined in the same way. This is more difficult [7,8]. We must first define R1 on the part [using the Coordinate Measuring Machine (CMM)]. R1 is associated with the part by numerical methods (least squares type).

For the particular case of individual part (Fig. 4), we have the following equation: (7)

That to say: (8)

thumbnail Fig. 4

Presentation of individual part.

3 Differences between two geometric movements

We will make the assumption that the two movements are known by their components p. It can therefore be represented by a point in a space of the same size p (space of individuals).

3.1 Small displacement torsor

The distance between the two displacements (individual and target) is often modeled by a torsor of small displacements (Fig. 5). It is assumed that the two reference systems are aligned (R1 target and R1 individual). Geometrically, we pass from the R2 target to the R2 individual by using a torsor of small displacement (linearization to first order).

thumbnail Fig. 5

Illustration of the field of geometric deviations.

3.1.1 Educational example

For example, it holds three parameters to know the difference, namely:

  • w: translation following axis Oz1;

  • α: rotation about axis Ox1;

  • β: rotation about axis Oy1.

The other three parameters are identically zero. A graphic illustration in three dimensions is possible.

4 Reflections on the distribution of the distance between two displacements

The objective of the analysis of displacements between “target and individual” is to determine all components of displacements (individual target) and show that some are very small compared to others. This will validate a 1D approach is generally sufficient and much simpler implementation.

4.1 Formatting data

We have n manufactured individuals. Each individual is characterized by components p (p ≤ 6).

The measurement protocol is as follows:

  • the measuring coordinate system is constructed from the three planes (A–B–C);

  • the association criterion of least squares is used to build the associated numerical element;

  • moving components machined upper plane (h = 30) (individuals) are calculated at the centroid of the element;

  • the measurement protocol of each part is defined in Table 1;

  • these data are grouped in an array X:

  • An individual ei is a vector at p components (it corresponds to a row in the array). A variable xj (column) is identified by the n measured values for the same parameter.

  • For our example, we get the following equation:


4.2 The space of individuals (displacements)

4.2.1 Center of gravity

Displacement (line) is defined by its p coordinates. It is an element of the space of individuals. The set of n individuals form a cloud of points with its center of gravity g: (11)

Either for the example (12)

It will be assumed that every individual has the same weight. The center of gravity is an indicator of the rightness of the means of production or measure.

4.2.2 Choice of a metric in the space of individuals

The components of the displacement have different units (angles and lengths). The general formula of distance is of the form: (13)

The most commonly used metric is (14) where s is the experimental standard deviation.

This is equivalent to multiplying each component by 1/s (this allows to be dimension less but with the drawback of si close to zero).

Either for our example: (15)

For example, the distance reduced between the 1 and 2 is equal to the following equation: (16)

4.2.3 Inertia

Inertia in g is equal to the following equation: (17)

We consider that every individual has a weight pi.

Either the inertia in O2cible (18)

The relationship of Huygens gives the following equation: (19)

This scalar indicator brings together the global dispersion of the gap field and its position relative to the target. Unfortunately, it is rather difficult to interpret in the case of physical parameters of a different nature. For our example, we get with (D=I) and (pi = 1): (20) with D = M, inertia is defined as the sum of squared distances reduced: (21)

This definition has the advantage of use values dimensionless.

5 Definition of compliance

In the conventional control frame, the p variables of the individual are defined by limits. Very often, these terminals are linked (not independent). For example, for the location of the upper surface, the link between the local variance α, β and w can be represented by a field of permissible differences [4,9].

The shape of the area deviations permitted depends strongly on the point of calculation of small displacements torsor (expressed in point O2cible in Fig. 6) [11].

The series of parts will be consistent, if the domain (or ball) measured deviations is included in the permissible differences field.

For our didactics example, variables angular α and β are not a problem. However, w represents the projection of the vector on the axis Oz2cible (or Oz1cible for this particular case). Referring to Section 2.1, we can write: (22)

In our case, we go from R1 to R2 by a simple translation, R is the identity I matrix. (23)

In doing so the scalar product with z2cible, yields well w: (24)

If the CMM, calculates the standard deviation w following this procedure, the location of the point O2individu is not fundamental.

thumbnail Fig. 6

The shape of the area deviations permitted.

6 The space of variables (components of displacement)

Each variable xj is a list of n numeric values. It can be represented by a vector of Rn.

The “vicinity” of variables will be given by the metric defined by the diagonal matrix of weights [12]. (25) with for example, pi = 1/n, so each individual has the same weight.

The scalar product of two variables xj and xk worth: (26)

If the variables are centered, the scalar product is the covariance sjk. The magnitude of a variable is given by . The angle θjk between two-centered variables is given by the following equation: (27)

The cosine is the linear correlation coefficient.

6.1 Covariance matrix

With weights equal to 1/n, we obtain: (28)

Either for our example: (29)

6.2 Linear correlation coefficients


6.3 Principal components analysis

In the most general case, we saw that we could have six settings by individual (three in this example). The principal component analysis allows us to have a representation of individuals by their projection in a lower dimensional, that with the minimum of distortion of the distances between individuals.

In our example, you can search if the two angular axes α and β can be replaced by a single axis (corresponding to that of greatest slope where assembly would result in a defect of systematic orientation). This is not the case for this experiment.

7 Experimentation

The experiment is carried out following 3 steps (Tab. 1):

  • Repeat a measurement of the same part with disassembly and reassembly on the fixture between each measurement (23 times). That allows to build a cloud of points, which shows the influence of the repositioning defect on the measuring machine.

  • Measurement of a sample of parts (23 parts). The parts were products over a long period of production. A complete setting of the machine was made for each part (gauges). The series of 23 parts was machining by students. Measuring gauge tools is therefore not strictly controlled. This can highlight the sources of production defaults.

  • The noise of measurement and the dispersion of recovery has been characterized by the following:

    • Center of gravity of the cloud of points (accuracy) (Tab. 2).

    • Inertia of the cloud of points (dispersion) (Tab. 3).

  • The spread of production has been characterized by the following:

    • Centre of gravity of the cloud of points (accuracy) (Tab. 4).

    • Inertia of the cloud of points (dispersion) (Tab. 5).

8 Conclusion

At present, production simulations favor a 3D approach [6,7]. But in a typical production system, angular instructions are rarely changed. Indeed, they are fit for mounting or machine tool (geometry). A good quality of the product fixation associated with very good geometry of machine tools take allows to control angular defects.

To obtain the geometrical conformity of a product, we need to verify that the displacement components defined previously remain below a threshold.

Otherwise, we can intervene only on some parameters of the means of production (origins programs, gauges …).

This means that other shortcomings noted only depend on the intrinsic quality of the means of production.

In this study, we are able to quantify the components of distance that cannot be changed by the control of the means of production.

The inertia indicators defined above enable to compare and classify different means of production.

From our results, we believe that a 1D simulation is often sufficient to validate the feasibility of a range of production. Figure 7 shows that the main defect found on the batch of manufactured parts corresponds to the component along the Z-direction. The components of angular defect are much lower [13,14].

This is identical to the fixture of the part of Figure 8. Main machining defect correction can be directly accomplished on machine tools using slight modification (gauges, correctives, origin of the frame). Angular defect correction requires significant changes (change of fixture or machining).

In summary, a simulation of production validated in a 1D approach has a high probability to see actual production to meet customer requirements.
